SKU: HP-D-Parent

Hotplates. Digital

Categories: SKU: HP-D-Parent
  • CE Certified
  • PL(Product Liability) Insurance
  • With Certificate & Traceability: Controlled by Serial Number, Certificate,
  • Delivery-information, and Traceable Data Base System
  • Excellent for Sample Drying and most General Lab Heating Applications
  • Superior Temperature Uniformity: Less than 10% on the Plate at an Ambient Temperature
  • Patented Jog-Shuttle Control System
  • Digital Feedback Control by High-Performance Microprocessor
  • Digital LCD Display with Back-Light Function, 0.1℃-Display, 0.5℃-Control
  • Temperature Accuracy: ±0.3℃ at Set Temp
  • Safety Circuit: Over Temp Protection
  • Timer: 99hr 59min (with Continuous run), Error status & Timer-end Alarm
  • Locking Mode for Experimental Safety Supported (Input to Jog Shuttle can be disabled)
  • User’s Self-Compensation: to Control the Difference between Real Temp & Indicated Temp (±20.0℃)

The Set option is supplied complete with an external temperature probe, support rod, and holder for temp. probe.


  Digital “HP-20D” Digital “HP-30D”
Plate Size(mm) 180×180mm Plate-type 260×260mm Plate-type
Material Body Powder Coated Aluminum Powder Coated steel
Plate Ceramic Coated Aluminum (Chemical / Acid Resistance, Easy to Clean)
Temp. Range & Uniformity Max. 380℃Temp., High Uniformity: Difference 10% less
Heating Power/Consumption 600 W 1.2 kW
Permissible Temp. & RH % R/T +5 ~ 50℃, 85% RH
Dimension & Weight 206×307×h99mm, 2.8kg 286×387×h99mm, 3.3kg
Packing Size & Gross Weight 400×280×h200mm, 5 kg 430×320×200hmm, 5 kg
Electrical Reqts. AC 230 V, 50 / 60 Hz
