The EVO HM1-10M Set from DAIHAN Scientific is a powerful, precision-engineered homogenizer ideal for laboratories and industrial applications. It’s designed for emulsifying, mixing, and dispersing even the most challenging samples with ease and accuracy.
Key Features
Brushless DC motor for quiet operation, smooth performance, and a long service life
Automatic reverse operation for more effective emulsification, especially when working with powders in liquids
Forward mixing can cause powders to scatter—reverse mode helps ensure proper absorption and mixing
Precise digital speed control protects equipment and ensures consistent results
Can be upgraded to a disperser with the optional DSTL Disper tool (same motor, different head)
Telescopic stand included for stable, adjustable setup
Large 3.5-inch high-resolution color touchscreen display
Programmable operation with up to 9 programs and 11 customizable steps
Made in Korea with robust stainless steel components for durability
What’s Included
Main motor unit
HMTL HomoMixer tool
Telescopic stand
Touchscreen display
Digital PID controller
USB port for data backup
Optional DSTL Disper tool (sold separately)
Technical Specifications
Specification
Details
Speed Range
500 – 13,000 rpm (no load)
Speed Resolution
50 rpm
Maximum Viscosity
70,000 mPas
Maximum Capacity
3 Liters (at max viscosity)
Motor Power
300 W
Direction Control
Forward and Reverse (auto switch)
Motor Type
Brushless DC
Safety Features
Overload, overcurrent, overheating protection, and error display
