- CE Certified
- with Certificate & Traceability: Controlled by Serial Number, Certificate, Delivery-information, and Traceable Data Base System
- Made of Stainless-steel, Finished Surface
- Analog Controller, Timer, Temperature and Output Control
- PL(Product Liability) Insurance
*Useful for Cleaning to Remove Dirt, Grease, Waxes, and Oil from all Lab Instruments by
* Ultrasonic Frequency
* Made of Stainless-steel, Finished Surface
* Analog Controller, Timer, Temperature and Output Control
* Temperature Ranges from Ambient to 85℃. (1.2 & 1.8 Lit : 65℃ Fixed)
* Convenient Preset Function : Heating and Timer
* HF-Frequency : 40kHz
* Bottom-Mounted Drain (WUC-A10H and WUC-A22H)
* Maximum 30 minutes of Cleaning Time (Except WUC-A10H)
| “WUC-A01H” Max. Capa. 1.2 Lit | “WUC-A02H” Max. Capa. 1.8 Lit | “WUC-A03H” Max. Capa. 3.3 Lit | “WUC-A06H” Max. Capa. 6 Lit | “WUC-A10H” Max. Capa. 10 Lit | “WUC-A22H” Max. Capa. 22 Lit | |
| Capacity | 1.2 Lit | 1.8 Lit | 3.3 Lit | 6 Lit | 10 Lit | 22 Lit |
| Frequency | 40KHz | |||||
| Heating Temp. | 65°C Fixed | 65°C Fixed | ambient to 85°C | ambient to 85°C | ambient to 85°C | ambient to 85°C |
| Heating Power | 86 W | 86 W | 172 W | 172 W | 258 W | 275 W |
| Timer | None | 0~30 min. | 0~30 min. | 0~30 min. | 0~30 min. | 0~30 min. |
| Drain-Valve | None | None | None | None | 1/2″ NPT | 1/2″ NPT |
| Tank Size (wxdxh)(inner (mm) | 150 x 135 x60 | 150 x 135 x 100 | 240 x 140 x 100 | 290 x 150 x 150 | 290 x 240 x 150 | 500 x 300 X 150 |
| Weight | 1.8 kg | 2.5 kg | 4 kg | 5.3 kg | 7 kg | 11 kg |
| Packing Dimension (wxdxh)(mm) | 200x200x190 | 200x200x240 | 320 200×290 | 370x220x350 | 430 x320x360 | 640x380x370 |
| Gross Weight | 3 kg | 4 kg | 5 kg | 6 kg | 7 kg | 11kg |
| Power Consumption | 158 W | 161 W | 296 W | 340 W | 523W | 654 W |
| Electrical Reqts. | 1 Phase, AC 230 V, 50/60 Hz | |||||
| Volume | 1.2Ltr, 1.8Ltr, 3.3Ltr, 6Ltr |
|---|
